The two guys sitting inside are either really brave or .......

Lightning Test Being Performed on a Northrop F-15 Reporter with the All Weather Flying Service.

_________________
A hypocrite is the kind of politician who would cut down a redwood tree, then mount the stump and make a speech for conservation.

I’ve heard it said: spirit is subtle. It’ll whisper in your ear. If you don’t listen, it’ll tap you on the shoulder. If you still don’t listen, it’ll break your arm. And after that…


Top
 Profile

PostPosted: Wed May 13, 2020 2:36 pm
Offline
1000+ Posts!
1000+ Posts!
User avatar

Joined: Thu Sep 23, 2004 3:00 pm
Posts: 1872
Location: Utah
In a Faraday cage I would assume.

Tom P.


Top
 Profile

PostPosted: Wed May 13, 2020 3:41 pm
Offline
1000+ Posts!
1000+ Posts!
User avatar

Joined: Fri Apr 30, 2004 8:11 am
Posts: 1909
Location: Montreal, Quebec, Canada
I may be wrong!

But that plexy canopy does not seem like a Faraday cage like a door on a microwave.

Saving grace could simply be the fact that they do not seem grounded with the air frame. Again. Could be wrong.

The hit would probably be in an area with the most metal mass density. I wonder if they even added lightning surge antennas to the biggest metal parts.

But for sure the interior must be padded with insulation material for the crew.

As always Mark!!!! Sublime. Anyone has a good read up on the bird and the testing?


Top
 Profile

PostPosted: Wed May 13, 2020 4:24 pm
Offline
1000+ Posts!
1000+ Posts!
User avatar

Joined: Wed Aug 18, 2010 12:51 pm
Posts: 1130
Location: Chandler, AZ
Neat close up on an F-15 even without the lightning.

Tom, makes you want to light up the array on the back 40, eh?

_________________
Lest Hero-worship raise it's head and cloud our vision, remember that World War II was fought and won by the same sort of twenty-something punks we wouldn't let our daughters date.


Top
 Profile

PostPosted: Wed May 13, 2020 4:33 pm
Offline
Long Time Member
Long Time Member
User avatar

Joined: Fri Apr 30, 2004 7:13 pm
Posts: 5243
Location: Minnesota, USA
Be sure to watch the live-test video as well. Starts at about the 9:00 mark.

https://www.youtube.com/watch?v=aE7VArI92As

_________________
It was a good idea, it just didn't work.


Top
 Profile

PostPosted: Wed May 13, 2020 6:54 pm
Offline
3000+ Post Club
3000+ Post Club

Joined: Mon May 03, 2004 1:05 am
Posts: 3037
wendovertom wrote:
In a Faraday cage I would assume.

Tom P.


Van Graaf (sp?) Generator?


Saludos


Tulio

_________________
Why take the best part of life out of your life, when you can have life with the best part of your life in your life?

I am one of them 'futbol' people.

Will the previous owner has pics of this double cabin sample

GOOD MORNING, WELCOME TO THE UNITED STATES OF AMERICA
Press "1" for English.
Press "2" to disconnect until you have learned to speak English.


Sooooo, how am I going to know to press 1 or 2, if I do not speak English????


Top
 Profile

PostPosted: Thu May 14, 2020 6:53 am
Offline
1000+ Posts!
1000+ Posts!
User avatar

Joined: Fri Apr 30, 2004 8:11 am
Posts: 1909
Location: Montreal, Quebec, Canada
Looks more like a Tesla coil.

To generate that kind of power you need a lot of energy.


Top
 Profile

PostPosted: Thu May 14, 2020 9:04 am
Offline
3000+ Post Club
3000+ Post Club

Joined: Mon May 03, 2004 1:05 am
Posts: 3037
Michel Lemieux wrote:
Looks more like a Tesla coil.

To generate that kind of power you need a lot of energy.


What he said.

I meant to,say Tesla Cpil, and Van Graaf came out.

Oh, well...not the first time I screw up.


Saludos.


Tulio

_________________
Why take the best part of life out of your life, when you can have life with the best part of your life in your life?

I am one of them 'futbol' people.

Will the previous owner has pics of this double cabin sample

GOOD MORNING, WELCOME TO THE UNITED STATES OF AMERICA
Press "1" for English.
Press "2" to disconnect until you have learned to speak English.


Sooooo, how am I going to know to press 1 or 2, if I do not speak English????


Top
 Profile

PostPosted: Thu May 14, 2020 9:48 am
Offline
User avatar

Joined: Tue May 16, 2006 10:06 am
Posts: 747
Location: Midland, Texas
I found that exact photo on page 122 of "Northrop's Night Hunter P-61 Black Widow" by Jeff Kolln, 2009. Chapter 9 is titled "Project Thunderstorm and NACA" and on page 122 is a discussion of "Lightning Tests". Basically the F-15A (45-59318) was flown to the Navy's Lightning and Transients Research Institute at then Wold-Chamberlain Field, now Minneapolis-St. Paul International, for the tests in February 1947. They say that the 40-foot high "generator device" could deliver up to 200,000 amperes at 100-million kilowatts. For the initial test the plane was drained of fuel and no crew was on board. Later, Lt. Eldor Schueler, the pilot, and Professor M.M. Newman volunteered to man the cockpit. It says "A metal conducting strip or diverter bar was mounted above the canopy of the F-15." There is some more detail on that page if you can access the book. Hope that helps.

Randy


Top
 Profile

PostPosted: Fri May 15, 2020 6:28 am
Offline
2000+ Post Club
2000+ Post Club
User avatar

Joined: Wed Jun 27, 2007 10:23 pm
Posts: 2200
Location: Atlanta, GA
Weather research, including the Black Widow, gets a fair amount of mention in Bob Buck's "North Star Over My Shoulder".

Ken

_________________
"Take care of the little things and the big things will take care of themselves."


Top
 Profile

PostPosted: Fri May 15, 2020 7:11 am
Offline
1000+ Posts!
1000+ Posts!
User avatar

Joined: Fri Apr 30, 2004 8:11 am
Posts: 1909
Location: Montreal, Quebec, Canada
Quote:
It says "A metal conducting strip or diverter bar was mounted above the canopy of the F-15."


Thank you Randy! I was curious about that.

I just wonder were the energy was diverted it the plane was not grounded. I guess if not grounded, the energy would have jumped to the ground on one of the oleo and simply bypass the rubber isolation of the tire.

But in the air....another story for sure.

Any good lighting strike story anyone?
